The Garvin Industries MC3CGHDG is a robust 1" mogul conduit body, C type with rollers, crafted from hot dip galvanized malleable iron. Designed for demanding electrical installations, this conduit body offers a long, large opening for easy pulling, splicing, and tapping of large or stiff conductors. It comes fully assembled with a raised cover, neoprene gasket, and stainless steel screws, ensuring reliable performance in wet locations.

Key Features and Benefits

• Built-in cable pulling roller for smoother, easier wire pulls
• Threaded NPT tapered hubs for Rigid and IMC conduit compatibility
• Smooth, round hub bushings protect conductor insulation
• Hot dip galvanized finish resists corrosion in harsh environments
• UL listed for wet locations and meets NEMA 3R standards
• Quick access for maintenance and future wiring changes
• Includes raised cover, neoprene gasket, and stainless steel screws for a secure, weather-resistant seal

Specifications

• Trade Size: 1"
• Material: Malleable iron body, neoprene gasket, stainless steel screws
• Finish: Hot dip galvanized
• Internal Volume: 19 in³
• Max Wire Size: 4 AWG
• Certifications: UL 514A/514D, NEMA FB 1-2014, NEMA 3R, Fed. Spec W-C-586D, A-A-50563

Common Uses

Perfect for industrial, commercial, and utility projects requiring large conductor pulls, splicing, or taps—especially where stiff wires or challenging runs are present.
