Green Creative Bypass and Hybrid Bypass PLS LED Lamp, 5.5W, 3000K, Hybrid Bypass, GX23 Base, Rotatable

By Green Creative
Green Creative Bypass and Hybrid Bypass PLS LED Lamp, 5.5W, 3000K, Hybrid Bypass, GX23 Base, Rotatable

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Green Creative Bypass and Hybrid Bypass PLS LED Lamp, 5.5W, 3000K, Hybrid Bypass, GX23 Base, Rotatable

$15.80
  • SKU: GC-5.5PLS/830/HYB/GX23/R
  • MPN: 5.5PLS/830/HYB/GX23/R

Quick Overview

5.5W hybrid bypass LED PL lamp for GX23 sockets, delivering 550 lumens at 3000K. Operates on 120-277V line voltage or compatible magnetic ballast, with 50,000-hour life for indoor damp-location fixtures.

UL Listed
NSF Listed
DAMP RATED
WARRANTY 5 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Green Creative Bypass and Hybrid Bypass PLS series is a versatile LED replacement platform for legacy CFL PL lamps in commercial fixtures. This 5.5PLS hybrid bypass model is designed to simplify upgrades by supporting both direct line-voltage operation and ballast-compatible installation. It is an important retrofit option in the lineup for improving efficiency, reliability, and maintenance cycles in indoor lighting applications.

Key Features and Benefits

  • Hybrid bypass flexibility allows operation with compatible magnetic ballasts or direct 120-277V wiring
  • Rotatable base design helps optimize light direction and fixture performance in horizontal installations
  • Shatter-resistant plastic body improves durability in demanding commercial environments
  • NSF certified for Food Zone (Non-Contact), Splash, and Non-Food areas for broader facility use
  • Backed by a 5-year limited warranty
  • Certified and tested for compliance with UL, FCC, and DOE reporting requirements

Specifications

  • Lumen Output: 550
  • Wattage: 5.5W
  • Voltage: 120-277V
  • Color Temperature: 3000K
  • CRI: 82
  • Power Factor: 0.9
  • THD: <20%
  • Beam Angle: 110°
  • Rated Life (L70): 50000 hours
  • Base Type: GX23 (2-pin)
  • Installation Orientation: Horizontal
  • Fixture Rating: Enclosed
  • Lamp Ambient Temperature: -4°F to 113°F
  • Fixture Operating Temperature: -4°F to 95°F
  • Dimensions (MOL x Dia.): 7" x 1-1/4"
  • Weight: 0.08 lb

Common Uses

Ideal for indoor general lighting retrofits in commercial buildings, schools, healthcare spaces, hospitality areas, and food-service support zones where GX23 CFL lamps are being replaced with longer-life, energy-saving LED technology.

RESOURCES AND DOWNLOADS

Green Creative Bypass and Hybrid Bypass PLS LED Lamp Spec Sheet
