Powerful LED CRL Engine & Driver Unit - 54W

Revamp your recessed lighting with our high-efficiency LED CRL engine and driver unit. Consuming only 54 watts yet delivering an impressive 4,500 lumens, this unit is your ideal solution for retrofitting CFL, HID, Metal Halide, and Incandescent lights. Available in three distinct color temperatures—3000K, 4000K, and 5000K—it's engineered to enhance any environment.

Top Features

Input Wattage: 54W
Color Rendering Index: >80
Efficacy: 83.3LM/W
Beam Angle: 40°
Long lifespan: 50,000 hours
Damp Rated

Electrical Specifications

Input Voltage: 100-277VAC 50/60Hz
Power Factor: ≥ 0.9

Housing & Build

Operating Temperature: Below 113°F
IP Rating: Suitable for damp locations

Exceptional Lighting

Dimmable: 0~10V dimmable
LED Type/Brand: CREE COB
Color Temperature Options: 3000K, 4000K, 5000K

Reliable Warranty

5-year limited warranty

RESOURCES AND DOWNLOADS

54 Watt LED CRL Engine & Driver Unit Spec Sheet

Light Source:	LED
Driver Type:	100~277V AC
Lumen Output:	4,500lm
Color Rendering Index (CRI):	>80
L70 Expected Life (hours):	50,000hrs
Color Temperature (CCT):	3000K
Color Temperature (CCT):	4000K
Color Temperature (CCT):	5000K
Total Input Watts:	54W
Lumen Output:	4500
Voltage:	120-277V
Primary Material:	Aluminum
Dimming Options:	0-10V
Power Factor:	>0.90
THD:	<20%
Operating Temperature:	113°F
L70 Expected Life (hours):	50,000
IP Rating:	Damp Location
LED Type:	LED
Lens Material:	PC Lens
Manufacturer's Warranty:	5 YEARS
Listings and Ratings:	UL
Country of Origin:	China
Item Weight (LBS):	0.98
Item Length (Inch):	6.1
Item Width (Inch):	7.2
Item Height (Inch):	11.2
