Introducing the ultimate solution for outdoor lighting needs, the Recessed Gas Station Canopy Light from Relight Depot. Engineered to perfection, this light comes with a power adjustable range of 80W, 100W, 120W, and 150W, delivering between 11,200 to 21,000 lumens. The 5000K color temperature ensures a bright, daylight-like experience, suitable for various commercial and public environments.
Features
- Constructed with ADC12 Aluminum Alloy and outdoor powder coating for enhanced durability.
- High transmittance polycarbonate optical lens that is anti-UV and fire-resistant.
- Backed by a comprehensive 7-year limited warranty.
- Multi-power selectable switch conveniently located on the side of the fixture.
Electrical Specifications
- Voltage: 120~277V AC, 50/60Hz.
- Power Factor: 0.95, ensuring efficient electrical performance.
- High efficacy of 140 lumens per watt (LM/W).
Mechanical Specifications
- Heavy-duty ADC12 Aluminum Alloy construction with a durable outdoor powder coating.
- Supports recessed mounting for versatile installation.
- Optional programmable bi-level motion sensor and emergency backup for added safety.
- Wide operating temperature range from -40°F to 104°F.
- IP65 rating, making it suitable for wet locations.
Lighting Specifications
- Compatible with 0~10V dimming systems for adjustable brightness.
- Powered by industry-leading Lumileds LEDs.
- Optical lens made of high transmittance PC, anti-UV and fire-resistant.
- Capable of emitting up to 21,000 lumens.
- Offers a daylight-like 5000K color temperature.
- Color Rendering Index (CRI) greater than 70, enhancing visual clarity.
- Wide beam angle of 100°x100° for broad coverage.
- Impressive lifespan of up to 70,000 hours.
Resources and Downloads
SKU | WM-GSX-RECS-80-150W-50K |
---|---|
Weight | 17.00 LBS |
Light Source | LED |
Fixture Size | 20.5"x20.5"x7.4" |
Color Rendering Index (CRI) | >70 |
Driver Type | 120-277VAC |
Lumen Output | 11,200-21,000lm |
Luminaire Efficacy Rating (LER) | 140lm/w |
L70 Expected Life (hours) | 70,000hrs |
Color Temperature (CCT) | 5000K |
Total Input Watts | 80W/100W/120W/150W |
Total Input Watts | 80W |
Total Input Watts | 100W |
Total Input Watts | 120W |
Total Input Watts | 150W |
Lumen Output | 140/W |
Voltage | 120-277V |
L70 Expected Life (hours) | 50,000 |
Listings and Ratings | UL, DLC |
