The 100W LED High Power Lamp with an E39 mogul base is an advanced lighting solution designed for efficiency and longevity. This high-performance lamp operates at 100 watts, emitting a remarkable 12,500 lumens with a crisp 5000K color temperature, making it perfect for a variety of applications, including retrofitting existing HID high bays. Rated for up to 50,000 hours of use and backed by a 5-year warranty, this lamp ensures long-lasting, reliable lighting in damp locations.
Features
- Lamp Base: E39 Mogul Base
- Warranty: 5-Year Warranty
- Housing: Durable Plastic Housing
- Lifespan: 50,000 Hours Rated Life
Electrical Specifications
- Voltage: 120-277V AC 50/60Hz
- Wattage: 100W
- Power Factor: >0.9
- THD: ≤25%
- Efficacy: 150 LPW
Mechanical Specifications
- Housing: Plastic Housing
- Cooling: No Fan Housing (New Technology)
- Base: E39 Mogul Base
- Operating Temperature: -4°F ~ 122°F
- Fixture: Not for Use in Enclosed Fixtures
- Location: Suitable for Damp Locations
Lighting Specifications
- Lens: PC Lens
- Total Lumens: 15000LM
- Color Temperature: Available in 3000K/5000K
- CRI: >80
- Beam Angle: 120°
- Lifespan: 50,000 Hours
Applications
- Ideal for retrofitting existing HID high bay applications, suitable for use in enclosed luminaires. Resources and Downloads
Resources and Downloads
| SKU | WM-HPL-HB-100W-50K-E39 |
|---|---|
| Weight | 16.00 LBS |
| Light Source | LED |
| Fixture Size | Other |
| Driver Type | 120-277V AC 50/60Hz |
| Lumen Output | 12,500lm |
| Luminaire Efficacy Rating (LER) | 150lm/W |
| L70 Expected Life (hours) | 50,000hrs |
| Color Rendering Index (CRI) | >80 |
| Color Temperature (CCT) | 5000K |
| Total Input Watts | 100W |
| Lumen Output | 12500 |
| Voltage | 120-277V |
| L70 Expected Life (hours) | 50,000 |
| Listings and Ratings | UL, DLC |
