Upgrade your lighting with our 2ft. LED T8 tube lens. This high-efficiency 15-watt tube emits a brilliant 1,725 lumens and is available in a 4000K color temperature, providing a cool, white light. Designed with a clear PC lens, it promises up to 50,000 hours of rated life and comes with a robust 5-year warranty for added peace of mind.
Features
- Type A + B (Dual UL) - Combine the benefits of using with an existing ballast or direct AC connection (ballast bypass) for versatile installation options.
- Type A: Compatible with Existing Ballast - UL No. E366061
- Type B: Ballast Override (AC Direct), Connect One End or Both Ends (Dual Function) - UL No. E342884
- Clear PC Lens for enhanced durability and light clarity
- 5-Year Warranty ensuring reliable performance
Electrical Specifications
- Voltage: 120-277V; 50/60Hz AC
- Power Factor: >0.90
- THD: <20%
- Wattage: 15W
- Efficacy: 115 LPW
Mechanical Specifications
- Base Type: G13
- Clear PC Lens
- Aluminum Housing & PC Lens
- Ambient Operating Temperature: -13°F to 113°F
- IP Rating: IP20 (Indoor)
Lighting Characteristics
- Base Type: G13
- Color Temperature: 4000K
- Lumen Output: 1,725 lm
- Clear PC Lens
- Rated Life: Up to 50,000 hours
Applications
- Perfect for retrofitting outdated fluorescent T8 tubes with energy-efficient LED technology. Ideal for commercial, residential, and industrial settings, offering both soft and bright light distribution.
RESOURCES AND DOWNLOADS
| SKU | WM-T8-EZ6-AHL-2FT-15W-40K-C |
|---|---|
| Weight | 1.00 LBS |
| Light Source | LED |
| Fixture Size | 2' Linear |
| Color Rendering Index (CRI) | ≥ 80 |
| Driver Type | 120-277V; 50/60Hz AC |
| Lumen Output | 1,725lm |
| Luminaire Efficacy Rating (LER) | 115 lm/W |
| L70 Expected Life (hours) | 50,000 hrs |
| Color Temperature (CCT) | 4000K |
| Total Input Watts | 15W |
| Lumen Output | 1725 |
| Voltage | 120-277V |
| Color Rendering Index (CRI) | >80 |
| L70 Expected Life (hours) | 50,000 |
| Listings and Ratings | DLC |
