Westgate Manufacturing ULHB Series – High Performance LED Lighting

The Westgate Manufacturing ULHB Series is engineered to deliver top-notch performance in a rugged package, making it an ideal choice for a variety of applications including general site lighting, alleys, loading docks, doorways, pathways, parking areas, warehouses, and storage buildings. This 150W model emits a bright, neutral white 4000K color temperature, ensuring excellent visibility and energy efficiency.

Key Features and Benefits

• Constructed with die-cast aluminum and a durable powder coat finish for enhanced longevity.
• Waterproof and resistant to aging and salt mist, ensuring reliability in various environments.
• Operates at 150W with an impressive efficacy of 130 lumens per watt, providing a total of 19,500 lumens.
• Designed for a long lifespan of up to 70,000 hours, reducing the need for frequent replacements.
• 0~10V dimmable feature for customizable lighting levels to suit your needs.
• Neutral 4000K color temperature for balanced, clear illumination.
• Comes with a robust 5-year warranty, ensuring peace of mind and reliable performance.

Technical Specifications

• Input Current: 2.03A
• Input Voltage: 120-277VAC 50/60Hz for flexible installation options.
• High power factor (>0.9) and low Total Harmonic Distortion (THD <20%) for efficient power usage.
• Operating temperature range: -4°F ~ 122°F, suitable for various climates.
• IP67 rating, making it perfect for wet locations.
• LED type/brand: SPMWH1228 for consistent, high-quality light output.
• Wide beam angle of 110° for extensive coverage.

Common Uses

Suitable for a wide range of applications such as general site lighting, alleys, loading docks, doorways, pathways, parking areas, warehouses, and storage buildings.
