Compact 3.5″ LED downlight with pinhole adjustable reflector, designed for architectural lighting applications. Offers selectable color temperatures and adjustable lumen outputs for versatile lighting.

Key Features and Benefits

• Adjustable trims allow precise, lockable aiming with 0°~30° tilt and 356° rotation.
• Interchangeable reflectors for different beam distributions.
• Dimming capability with 0-10V, ELV & TRIAC dimmer switches.
• Optional Lutron Hi-lume drivers for smooth, continuous dimming down to 1%.
• Available in various finishes for customizable aesthetics.

Specifications

• Input Voltage: 120~277V
• Wattage: 14W
• Lumen Output: 1,187 lm
• Efficacy: 86.9 LPW
• CCT: 2700K, 3000K, 3500K, 4000K
• CRI: 80, 90
• Lifespan: 50,000 hours
• Certifications: cETLus Listed, LM-79 compliant

Common Uses

Ideal for architectural lighting in commercial and residential spaces, providing precise and adjustable illumination for accent, task, and general lighting applications.
