Single face clear edge lit exit sign with battery backup, 3 watts, average 50 cd/m2 lumens/illuminance, up to 24 hours recharge time, suitable for damp locations, 5 years limited warranty.
EASY TO INSTALL SAFETY SOLUTIONS FOR NYC
Topaz’s LED Edge-Lit Exit Signs are the ideal safety solution for NYC office, industrial, retail and public places. Always ensure exits are clearly marked, even in the event of a power failure with the built-in 90-minute battery backup. These modern units have a clean look, with clear or mirrored panel and 8” red EXIT letters. Surface mount installation is easy with the included canopy and mounting accessories.
FEATURES
- New York City approved
- Meets NFPA 70, NFPA 101, UL924, NEC/OSHA Standards
- Battery backup with accessible test button for 90 minutes of illumination during a power outage
- Clear, single face or mirrored, double face configurations available
- Configurable arrows
- Ceiling, wall, or side mounting capability
APPLICATIONS
- Office, industrial, retail and other public spaces
- New York City applications
GENERAL SPECIFICATIONS
- Input Voltage, Frequency Hz: 120/277V, 60Hz
- Emergency Backup: Yes
- Emergency Duration / Run Time: 90 minutes
- Recharge Time : 24 hours
- Recycle Times: 500 cycles
- Mounting Height: 7.5 ft to 15 ft
- Location Rating: Damp
- Ambient Operating Temperature : 50°F to 104°F
- Battery Type: 4.8V Ni-Cad
RESOURCES AND DOWNLOADS
| SKU | TPZ-ESEL/SFS/RCL/B-NYC |
|---|---|
| Weight | 4.00 LBS |
| Light Source | LED |
| Fixture Size | - |
| Driver Type | 120/277V, 60Hz |
| Lumen Output | Average 50 cd/m2 |
| Total Input Watts | 3W |
