6-Inch LED Recessed Light Trim
Illuminate your space with our versatile 6-inch LED recessed light trim. Designed to be power-selectable, this fixture operates at 10, 13, or 17 watts and provides a variety of color temperatures (CCT), including 2700K, 3000K, 3500K, 4000K, and 5000K. With an efficacy of 80 lumens per watt, this white-finish light ensures brilliant lighting up to 50,000 hours. Suitable for both indoor and outdoor wet locations, enjoy peace of mind with a 5-year warranty.
FEATURES
- 6" Baffle Recessed Trim
- JA8-E-2019 & Title 24 Compliant (California Energy Commissions approved)
- 5-Year Warranty
- Composite Polycarbonate
- Multi CCT and Power Selectable (Switch on the Driver)
ELECTRICAL
- Voltage: 120V AC
- Power Factor: >0.90
- Wattage Options: 17W/13W/10W
- Efficacy: 80 LPW
- Total Harmonic Distortion: ≤15%
MECHANICAL
- Composite Polycarbonate, White Finish
- Max Ambient Temperature: 104°F
- Includes 8” Medium Base E-26 Screw-in Adapter
- Fits Standard and Shallow 5” & 6” Recessed Housings
- White Translucent Acrylic Lens
- Wet Location Rated, O-Ring Installed
- 5-Year Warranty
LIGHTING
- Dimming: TRIAC Dimming (Standard TRIAC LED Dimmers)
- Total Lumens: upto 1360LM
- Color Temperatures: 2700K/3000K/3500K/4000K/5000K
- CRI: ≥90
- Rated Life: 50,000 hours
APPLICATIONS
- Ideal for retrofit and new construction applications, perfect for closets, storage areas, attics, corridors, or as general lighting solutions for residential and commercial spaces.
RESOURCES AND DOWNLOADS
6" LED Recessed Light Trim, 10W-17W Power and CCT's Spec Sheet
SKU | WM-RDPF6-MCTP |
---|---|
Weight | 1.00 LBS |
Light Source | LED |
Fixture Size | 6" Round |
Driver Type | 120V AC |
Lumen Output | 80lm |
Luminaire Efficacy Rating (LER) | 80lm/W |
L70 Expected Life (hours) | 50,000hrs |
Color Rendering Index (CRI) | >90 |
Color Temperature (CCT) | MCT |
Total Input Watts | 10W/13W/17W |
Total Input Watts | 10W |
Total Input Watts | 13W |
Total Input Watts | 17W |
Lumen Output | 80/W |
Color Temperature (CCT) | 2700K |
Color Temperature (CCT) | 3000K |
Color Temperature (CCT) | 3500K |
Color Temperature (CCT) | 4000K |
Color Temperature (CCT) | 5000K |
Voltage | 120V |
Color Rendering Index (CRI) | 90 |
L70 Expected Life (hours) | 50,000 |
Listings and Ratings | UL |
