DMX 512 compatible RGBW round LED flood light, 144 watts, 2,700-7,300 lumens, available in RGBW selectable color temperature (CCT), IP65, suitable for wet locations, 7 year warranty.
FEATURES
- Die-cast Aluminum Housing with Powder Coat Finish
- Adjustable Yoke Bracket
- 7-Year Warranty
- Lens Type: Plaid Tempered Glass + Aluminum Reflectors
ELECTRICAL
- Voltage: 120-277V
- Power Factor: >0.9
- Wattage: 144W
- Efficacy: 51 LPW
- Operating Voltage: Max 900 mA, Max 36VDC
- In A DMX Lighting Setup, Lights Need To Be Connected With cables. The Cables Can Be “Daisy Chained”So That Each Light Can Plug Into The One Before ItInstead Of All Lights Plugging Into The DMX Board Itself
MECHANICAL
- Die-cast Aluminum Housing with Powder Coat FinishSolid State Lighting Technology for Long Life, No Maintenance Needed and High-Efficiency
- Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- High Conductive Aluminum LED Board
- Adjustable Yoke Bracket
- Operating Temperature: -40°F to 104°F
- IP Rating: IP65, Suitable for Wet Locations
LIGHTING
- Dimming: Dimmable Through Phone App
- Total Lumens: 2700LM(Single White) 7300LM(Maximum Power)
- Color Temperatures:RGBW Seletable Through DMX Controller
- Color Rendering Index: CRI ≥ 80
- Beam Angle: 60°
APPLICATIONS
- The fixture has classic traditional appearance,professional light distribution design, 90-degree beamangle, ideal for park landscaping, garden, architectural landscape lighting, suitable for wet locations.
RESOURCES AND DOWNLOADS
| SKU | WM-DMX-FLS-144W-RGBW-BT-BK |
|---|---|
| Weight | 16.00 LBS |
| Light Source | LED |
| Driver Type | 120-277V |
| Lumen Output | 2,700lm-7,300lm |
| Luminaire Efficacy Rating (LER) | 51lm/W |
| Color Rendering Index (CRI) | > 80 |
| Color Temperature (CCT) | RGBW |
| Total Input Watts | 144 |
| Total Input Watts | 144W |
| L70 Expected Life (hours) | 70,000 |
