The Aleo EDL Series is the perfect energy-saving solution for commercial downlight applications. The EDL recessed downlight offers extreme versatility with field-adjustable lumen output and color temperature. No can is needed for installation, making it perfect for new construction or retrofit of CFL and HID downlights of varying mounting heights.

Key Features and Benefits

• Field-selectable lumen output and color temperature for increased versatility
• Durable powder coat finish and integrated spring-action clips for easy installation
• IC-rated and Wet Location Rated for diverse application use
• Reflector system with optimal glare control and smooth illuminance
• ETL Listed and FCC Part 15 Class B certified
• Continuous 0-10V dimming standard
• 7-year limited warranty

Specifications

• Input Voltage: 120V-277V
• CRI: 90+
• Rated Life: 50,000 hours
• Lumen Package: 1500lm - 2600lm
• Wattage: 16W - 30W
• Efficacy: 88-107 lm/W
• Available CCT: 2700K, 3000K, 3500K, 4000K, 5000K

Common Uses

Ideal for commercial, retail, education, hospitality, and covered outdoor ceilings. Suitable for both retrofit/remodel and new construction projects.
