An LED emergency driver that allows the same LED fixture to be used for both normal and emergency operation, featuring integrated self-diagnostic circuitry that automatically conducts regular tests to verify proper emergency capability.

Key Features and Benefits

• Self-diagnostic circuitry performs annual/monthly testing automatically, reducing maintenance costs
• Auto-adjusting Class 2 25-50VDC output accommodates a wide range of forward voltage LED designs
• Constant power design provides constant light output for 90 minutes
• UL Listed for field installation
• Two different form factors allow for greater flexibility when adding to fixtures

Specifications

• Input voltage: 120-277V 50/60Hz
• Input power: 7W (max)
• Output voltage: 25-50VDC
• Power Factor: >0.85
• Operating Temp: 0°C - 50°C
• Emergency operation: ≥90 mins
• Recharge: 24 hrs
• Long-life, maintenance-free, high temperature, recyclable lithium battery
• 5 year limited warranty

Common Uses

Ideal for use in LED fixtures for both normal and emergency lighting, ensuring continuous illumination during power outages.
