The Garvin Industries LL6SS is a 2" EMT and rigid combination conduit body designed for reliable access to conductors for pulling, splicing, and maintenance. This LL type conduit body is crafted from copper-free aluminum and finished with a durable powder coat, making it suitable for use in concrete and wet locations. It stands out in Garvin's lineup for its robust construction and compliance with stringent industry standards.

Key Features and Benefits

• Combination LL type for versatile installations
• NPT tapered hubs ensure secure connections
• Suitable for use in concrete and wet locations
• Constructed from copper-free aluminum for corrosion resistance
• Durable powder coat finish for long-lasting protection
• UL listed and NEMA FB 1 rated for safety and compliance
• Provides easy access for conductor pulling, splicing, and maintenance

Specifications

• Size: 2"
• Max Wire Size: 2/0 AWG
• Material: Copper-free aluminum die cast
• Finish: Powder coat
• Certifications: UL 514A, Fed. Spec. W-C-586D, NEMA FB 1
• Dimensions: 10.48" (A) x 3.29" (B) x 4.07" (C)

Common Uses

Ideal for commercial, industrial, and residential conduit installations where durable and accessible conductor management is required, especially in wet or concrete environments.
