The Garvin Industries LR10CG is a 4" threaded LR type conduit body, complete with a cover and gasket. Designed for durability and reliability, this conduit body is a key solution for electrical installations requiring access to conductors for pulling, splicing, and maintenance.

Key Features and Benefits

• Includes cover and neoprene gasket for a secure, weather-resistant seal
• Threaded NPT tapered hubs for easy installation
• Constructed from copper-free aluminum die cast for corrosion resistance
• Powder coat finish for added durability
• UL listed and meets NEMA FB 1 and Fed. Spec. W-C-586D standards
• Suitable for use in concrete and wet locations

Specifications

• Conduit Size: 4"
• Material: Copper-free aluminum body, stamped steel cover, neoprene gasket
• Finish: Powder coat
• Certifications: UL 514A, NEMA FB 1, Fed. Spec. W-C-586D
• Dimensions: 15.50" (A) x 5.452" (B) x 6.171" (C)
• Max Wire Size: 350 MCM

Common Uses

Ideal for commercial, industrial, and residential electrical installations where access to conductors is needed for pulling, splicing, or maintenance, especially in wet or concrete environments.
