The Garvin Industries LR2SS is a 3/4" LR type EMT and rigid combination conduit body, designed to provide easy access to conductors for pulling, splicing, and maintenance. Built from copper-free aluminum with a durable powder coat finish, this conduit body is NEMA FB 1 rated for wet locations and features NPT tapered hubs for secure connections. Its robust construction and UL certification make it a reliable choice for demanding environments.

Key Features and Benefits

• Combination LR type for versatile conduit runs
• NPT tapered hubs ensure a tight, secure fit
• Suitable for use in concrete and wet locations
• Constructed from copper-free aluminum for corrosion resistance
• Powder coat finish for added durability
• UL listed and NEMA FB 1 rated for safety and compliance
• Provides convenient access for wire pulling, splicing, and maintenance

Specifications

• Trade Size: 3/4"
• Maximum Wire Capacity: 2 wires of 6 AWG
• Material: Copper-free aluminum
• Finish: Powder coat
• Certifications: UL 514A, Fed. Spec. W-C-586D, NEMA FB 1
• Dimensions: 5.31" (A) x 1.62" (B) x 2.23" (C)

Common Uses

Ideal for commercial, industrial, and residential conduit installations where access to conductors is needed for pulling, splicing, or maintenance, especially in wet or concrete environments.
