The Garvin Industries LR3SSCG is a 1" EMT and rigid combination conduit body, complete with a cover and gasket. This LR type conduit body is an essential part of Southwire's lineup, offering reliable access for pulling, splicing, and maintenance of conductors in challenging environments.

Key Features and Benefits

• Durable copper-free aluminum die-cast construction for long-lasting performance
• Includes stamped steel cover and neoprene rubber gasket for a secure, weather-resistant seal
• NPT tapered hubs ensure a tight, reliable fit
• Rated for wet locations and suitable for use in concrete
• NEMA FB 1 rated, UL 514A listed, and meets Fed. Spec. W-C-586D for safety and compliance
• Powder-coated finish for added corrosion resistance

Specifications

• Trade Size: 1"
• Max Wire Size: 3 x 6 AWG
• Material: Copper-free aluminum body, stamped steel cover, neoprene gasket
• Finish: Powder coat
• Dimensions: 6.25" (A) x 1.88" (B) x 2.50" (C)
• Certifications: UL 514A, Fed. Spec. W-C-586D, NEMA FB 1

Common Uses

Ideal for commercial and industrial electrical installations, especially where access to conductors is needed for pulling, splicing, or maintenance in wet or concrete-embedded locations.
