The Garvin Industries MLR4CGHDG is a robust 1-1/4" LR type mogul conduit body, crafted from hot dip galvanized malleable iron and designed for durability in demanding environments. It comes complete with a raised cover, gasket, and stainless steel screws, making it ideal for wet locations and heavy-duty applications.

Key Features and Benefits

• Hot dip galvanized malleable iron body for superior corrosion resistance
• Includes raised cover, neoprene gasket, and stainless steel screws for a secure, weather-resistant seal
• Threaded NPT tapered hubs fit rigid and IMC conduit
• Integral hub bushings protect conductor insulation
• Provides easy access for wiring maintenance and future changes
• Large internal volume accommodates up to 2 AWG conductors
• cULus listed for wet locations and meets NEMA 3R standards

Specifications

• Size: 1-1/4"
• Max Number of Conductors: 3
• Max Conductor Size: 2 AWG
• Internal Volume: 25 in³
• Material: Malleable iron, hot dip galvanized finish
• Certifications: UL 514A, UL 514D, NEMA 3R, Fed. Spec W-C-586D, A-A-50563

Common Uses

Perfect for pulling, splicing, and tapping large conductors in commercial and industrial conduit runs, especially where moisture protection and durability are critical.
