The Garvin Industries LL7CG is a robust 2-1/2 inch threaded LL type rigid conduit body, complete with a cover and gasket. Engineered for durability and reliability, this conduit body is an essential part of Southwire's lineup, offering secure access for pulling, splicing, and maintaining conductors in challenging environments.

Key Features and Benefits

• Threaded LL type design for easy installation and maintenance
• Includes cover and neoprene rubber gasket for a secure, weather-resistant seal
• Constructed from copper-free aluminum die cast for superior corrosion resistance
• Powder coat finish enhances durability and longevity
• Suitable for use in wet locations and concrete applications
• NPT tapered hubs ensure a tight, reliable fit
• UL listed and meets NEMA FB 1 and Fed. Spec. W-C-586D standards

Specifications

• Size: 2-1/2"
• Material: Copper-free aluminum body, stamped steel cover, neoprene rubber gasket
• Finish: Powder coat
• Certifications: UL 514A, NEMA FB 1, Fed. Spec. W-C-586D
• Dimensions: 13" (A) x 4.063" (B) x 5.709" (C)
• Max Wire Size: 4/0 AWG

Common Uses

Ideal for providing access to conductors for pulling, splicing, and maintenance in commercial, industrial, and outdoor electrical installations, especially where wet or concrete environments are present.
