The Garvin Industries LL7G7 is a robust rigid conduit body from the trusted Form 7 series, designed for demanding electrical installations. This 2-1/2" LL type body offers superior protection and flexibility for pulling and splicing wires in commercial and industrial environments.

Key Features and Benefits

• NPT tapered hubs for secure, easy installation
• Raintight (NEMA 3R) when installed with cover and gasket
• Suitable for Class 1 Div.2 hazardous locations per NEC 2014
• Eco-friendly, corrosion-resistant zinc-plated finish
• Highly resistant to solvents, fuels, and acids
• UL 514A/514D and NEMA FB 1 certified for safety and reliability
• Spacious 95.8 in³ internal volume for easy wire management

Specifications

• Hub Size: 2-1/2"
• Maximum Conductors: 3
• Maximum Wire Size: 250 MCM
• Internal Volume: 95.8 in³
• Material: Gray iron
• Finish: Zinc plated, corrosion resistant
• Certifications: UL 514A/514D, NEMA FB 1, Fed. Spec A-A-50563
• Dimensions: 10.70" (A) x 5.80" (B) x 3.70" (C)

Common Uses

Ideal for commercial, industrial, and hazardous locations where a durable, raintight conduit body is needed for pulling, splicing, and changing wire direction.
