LH1 Pro Linear High Bay, 160/130/110/90W, 4000/5000K, Field Color Selectable

No reviews yet Write a Review
Ask Questions
LH1 Pro Linear High Bay, 160/130/110/90W, 4000/5000K, Field Color Selectable
LH1 Pro Linear High Bay, 160/130/110/90W, 4000/5000K, Field Color Selectable

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

LH1 Pro Linear High Bay, 160/130/110/90W, 4000/5000K, Field Color Selectable

$160.75
  • SKU: E-LH1-PS160-FCCT-H
  • MPN: LH1-PS160-FCCT-H
  • Shipping: Calculated at Checkout

Quick Overview

The LH1 Pro Linear High Bay offers selectable wattage (160/130/110/90W) and color temperature (4000/5000K) with adjustable lumen outputs, perfect for versatile lighting needs.

In Stock & Ready To Ship!
Current Stock:Only left:

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The LH1 Pro Linear High Bay offers selectable wattage (160/130/110/90W) and color temperature (4000/5000K) with adjustable lumen outputs, perfect for versatile lighting needs.

Key Features and Benefits

  • PowerSET with 4 Power settings
  • FieldCCeT with 2 CCT settings (4000/5000K)
  • Wide range of lumen packages (13,500 – 66,000 lumens)
  • Diffused polycarbonate lens for reduced glare (beam angle 90°)
  • Die cast aluminum housing and impact resistant lens
  • CRI >80, Efficacy up to 150 LPW
  • Lumen Maintenance 70% (L70) at > 100,000Hrs
  • THD <20%, Power Factor >0.9
  • Surge Protection: 6kV included
  • DesignLights Consortium® (DLC) Premium listed

Specifications

  • Selectable wattage: 160/130/110/90W
  • Selectable color temperature: 4000/5000K
  • Lumen output: 24,000/19,500/16,500/13,500 lm
  • Input voltage: 120-347V

Common Uses

Warehouses, Distribution Centers, Grocery Stores, Gymnasiums, Data Centers, Manufacturing Plants, Cold Storage, Big Box Retail, Indoor Recreational Facilities, Vehicle Maintenance Facilities

RESOURCES AND DOWNLOADS

LH1 Pro Linear High Bay Spec Sheet
