The 4" LED Architectural Frame-in Kit is a versatile lighting solution designed for non-insulated ceilings, perfect for a variety of settings. It is part of a renowned series known for its high performance and adaptability.

Key Features and Benefits

• High efficacy LED engine with options of 10W, 14W, 22W, or 32W.
• Selectable color temperatures: 2700K, 3000K, 3500K, and 4000K.
• Universal dimmable drivers compatible with Triac, ELV, and 0-10V dimmers.
• Special optical diffuser for high lumen transmission and even illumination.
• Suitable for wet locations, ensuring versatility in application.
• 5-year LED module warranty, 3-year product/driver warranty.

Specifications

• Input Voltage: 120-277VAC
• Wattage: 14W
• Lumen Output: 1,400 lm
• Efficacy: 100 lm/W
• CRI: 80, 90
• Beam Angle: 67.7°
• Certifications: California Title 24, cCSAus

Common Uses

Ideal for commercial and residential applications such as offices, retail spaces, and hospitality environments where high-quality, adjustable lighting is essential.
