13 Watt U-Bend T8 Directfit Lamp

PRODUCT DESCRIPTION

MaxLite DirectFit LED T8 U-bend lamp is the ideal plug and play solution that works straight out of the box. Designed to deliver over 1800 lumens, these energy-saving LED lamps are quick, easy and safe to install into existing linear fluorescent fixtures without any extra effort or re-wiring. MaxLite DirectFit LED T8 U-bend lamps utilize the existing T8 instant-start electronic ballasts, thus minimizing maintenance and labor costs.

FEATURES

• Wattage (Bare Lamp): 13W, System wattage: 16W
• Equivalent: 32W Fluorescent T8, 59% Energy saving
• Lumens: 1800lm
• Input Voltage: 120-277, 347V VAC, determined by fluorescent ballast
• Compatible with most electronic instant-start T8 ballasts
• Eliminates the need for rewiring
• Polycarbonate lens with 320° beam angle
• Color Rendering Index (CRI): 83
• THD <20%
• Power Factor: 0.90
• Instant on
• Dimmable (see compatible ballast list on models)
• Suitable for use in damp locations
• Suitable for use in totally enclosed recessed fixture
• Not for use or to be wired to “mains voltage”
• No mercury, easy disposal
• Rated Lifetime @ L70: 50,000 Hours
• U13T8DF2xx is listed on the DLC QPL (“xx” = 35 (3500K), 40 (4000K) or 50 (5000K)

APPLICATIONS

• Hospitals
• Medical Offices
• Restaurants
• Fast Food Chains
• Department Stores
• Hallways

WARRANTY

• 5-year standard warranty (further details available at www.maxlite.com/warranties)

  • Product may be eligible for a warranty extension to 10 years, for an additional fee. Contact MaxLite for details.
