REL23 Series, Narrow Lens Self-diagnostic Emergency Unit with Wet Location Option

This compact, low-profile, high-output, self-contained REL23 Series emergency unit from RP Lighting and Fans is designed for efficient operation and easy installation. The narrow lens and self-diagnostic feature, coupled with the wet location option, make it highly versatile for various environments.

Key Features and Benefits

• Self-diagnostic functionality for automatic monitoring and testing
• Dual adjustable 1.4W LED heads for a total of 247 lumens
• 120/277V AC dual voltage capability
• 3.6V, 800 mAh rechargeable Ni-Cad battery with a 48-hour recharge time
• 90 minutes of emergency illumination
• UL Listed for damp locations and meets NFPA life safety codes
• 5-year limited warranty on LED light source; 1-year on other components

Specifications

• Operating temperature: -10°C (14°F) to 40°C (104°F) with cold weather option
• Wet location cover included in wet location option
• Easy installation on ceiling or wall over standard recessed J-Box

Common Uses

Perfect for a variety of settings requiring emergency lighting solutions, including long hallways, large spaces, and areas subject to wet conditions.
