High efficacy round high bay with selectable color temperature (3500K, 4000K, 5000K) and adjustable lumen outputs (36,000/30,000/27,000 lm).
Key Features and Benefits
- Controls Ready for easy control installation
- Includes 10ft power and dimming cord and hook for easy installation
- PowerSet feature for multiple lumen settings
- FieldCCeT feature for multiple color temperature settings
- UL Certified for US & Canada
- RoHS and FCC Compliant
- IP65 Rated
- DesignLights Consortium® Premium Qualified
- NSF listed for Splash Zone and Non-Food Zone
Specifications
- High efficacy, up to 150 lm/W
- Available wattage: 240/200/180W
- Field-selectable CCT: 35/40/5000K
- CRI: >80
- Beam Angle: 90°
- Estimated L70: 100,000 Hours
- Input voltage: 120-277V
- 0-10V dimming, dim-to-off
- Surge protection: 6kV
- Power factor: >0.9
- THD: <20%
- Operating temperature: -40°F to 122°F (-40°C to 50°C)
- Construction: Matte black or white powder coated, Die cast Aluminum
- Impact-resistant polycarbonate lens
Common Uses
Warehouses, Manufacturing Plants, Distribution Centers, Grocery Stores, Gymnasiums, Indoor Recreational Facilities, Cold Storage, Big Box Retail, Service Repair Centers.
RESOURCES AND DOWNLOADS
| SKU | E-BAYE3-PS240-FCCT-U |
|---|---|
| Weight | 16.00 LBS |
| Lumen Output | 36,000/30,000/27,000 |
| Total Input Watts | 240/200/180W |
| Voltage | 120-277V |
| Color Temperature (CCT) | 3500/4000/5000K |
| Color Rendering Index (CRI) | >80 |
