Steel Housing LED Emergency Unit

DESIGN FEATURES

ILLUMINATION

• Long lasting, efficient, ultra bright white LED lamp heads.
• 1.5 watt, (12 LEDs x 0.125 watt) per head.
• High performance chrome-plated metallized reflector and plastic lens for optimal light distribution.
• Adjustable LED lamp heads provide optimal center-to-center spacing.

ELECTRICAL

• Dual 120/277 voltage.
• Charge rate/power "ON" LED indicator light and push-to-test switch for mandated code compliance testing.
• LVD (low voltage disconnect) prevents battery from deep discharge.
• 6V sealed lead acid, maintenance-free, rechargeable battery.
• Remote capacity of 20.0 watt standard.
• Runs up to 8 hours without remote heads.
• Internal solid-state transfer switch automatically connects the internal battery to the LED lamp heads for minimum 90-minute emergency illumination.
• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.

MOUNTING

• Universal knockout pattern on back plate for wall mount.
• Side and top knockouts for conduit feed applications.

HOUSING

• Durable 90-gauge steel construction in white or black finish.
• Injection-molded engineering grade high-impact thermoplastic lamp heads

WARRANTY / LISTING

• Five year warranty on all electronics and housing. Battery prorated for two years.
• UL Listed for damp locations (20°C - 50°C) standard.
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
