Name: 16.4Ft. LED Ribbon Light, 24V Ultra High Output
Brand: Westgate Manufacturing
SKU: WM-ULR-IN-16F-YHO
Price: 61.74 USD
Availability: InStock

Description

Details

Product Reviews

Description

Series Summary

Model No.	CCT	Watts per FT.	Reel Length	Lumens per FT.	Width	Max Run
ULR-IN-16F-YHO-50K	5000K	6.7	116.4 ft.	900	0.4 in.	14 ft.
ULR-IN-16F-YHO-40K	4000K	6.7	116.4 ft.	880	0.4 in.	14 ft.
ULR-IN-16F-YHO-30K	3000K	6.7	116.4 ft.	850	0.4 in.	14 ft.
ULR-IN-16F-YHO-27K	2700K	6.7	116.4 ft.	850	0.4 in.	14 ft.

Technical Specifications

LED: SMD2835 chip spaced 1/3” on center, 39 LED per foot, 0.17 watts each chip
Dimmable using a magnetic driver
Cutting increment: Every 2.5 inches
Working voltage: 24V DC (LED driver required)
Power: 6.7 watts per foot
Lumens: 914 lumens per foot, 24 LM per LED
CRI: 80
Max run: 14'
120º beam angle
The 3M double-sided tape is preinstalled
Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
Operating temperature: -4ºF - 104ºF
IP20
5-year warranty

Applications

Perfect for undercabinet lighting, soffits, display cases, and toe kick lighting.

Resources and Downloads

Indoor Ultra High Output Spec Sheet

Details

Light Source:	LED
Fixture Size:	4' Linear
Color Rendering Index (CRI):	80
Driver Type:	24V
Lumen Output:	850-900
Color Temperature (CCT):	2700K
Color Temperature (CCT):	3000K
Color Temperature (CCT):	4000K
Color Temperature (CCT):	5000K
Total Input Watts:	6.7
Total Input Watts:	6.7W/FT
Lumen Output:	820/FT
Voltage:	24VDC
Primary Material:	PCB
Dimming Options:	Dimmable using magnetic driver
Color Rendering Index (CRI):	90
Operating Temperature:	-4°F to 104°F
Beam Angle Options:	120°
L70 Expected Life (hours):	50,000
IP Rating:	IP20
LED Type:	SMD
Manufacturer's Warranty:	5 YEARS
Listings and Ratings:	UL
Country of Origin:	China
Item Weight (LBS):	0.36
Item Length (Inch):	7.1
Item Width (Inch):	7.2
Item Height (Inch):	0.8
Lumen Output:	880/FT
Lumen Output:	900/FT
