Versatile LED Troffer Light for Multiple Applications
Transform your commercial spaces with the high-performance WM-LTRE-1X4-MCTP LED Troffer Light, specifically designed for maximum efficiency and versatility. Ideal for various environments, including hotels, offices, retail outlets, restaurants, parking garages, storage rooms, conference rooms, and educational facilities.
Technical Specifications
- Built with cold-rolled steel, measuring 2.6” in thickness
- Input Voltage: AC120V-277V, 50/60Hz for flexible installation
- Power Factor: 0.97
- High efficiency with 125LM/W output
- Color Rendering Index (CRI): Over 80 for true color representation
- Total Harmonic Distortion (THD): Less than 20%
- Dimmable via 0~10V dimming capabilities
- IP Rating: IP20 for indoor use
- Operates in ambient temperatures ranging from -4°F to 122°F
- Long-lasting with a rated life of 50,000 hours
- 5-year warranty for peace of mind
Key Features
- Exclusive lens design installs from the ends to prevent light leakage, ensuring a seamless look
- Earthquake hooks integrated into the housing for enhanced safety
Ideal Applications
This LED troffer light is a perfect one-for-one replacement for conventional fluorescent troffer fixtures, enhancing lighting quality and energy efficiency.
Product Dimensions
Dimensions: 12-3/4" x 47-3/4" x 2-1/2"
Resources and Downloads
RESOURCES AND DOWNLOADS
| SKU | WM-LTRE-1X4-MCTP |
|---|---|
| Weight | 16.00 LBS |
| Light Source | LED |
| Fixture Size | 1X4 |
| Color Rendering Index (CRI) | >80 |
| Driver Type | AC120V-277V |
| Luminaire Efficacy Rating (LER) | 125 lm/W |
| Color Temperature (CCT) | 3500K |
| Color Temperature (CCT) | 4000K |
| Color Temperature (CCT) | 5000K |
| Total Input Watts | 26W |
| Total Input Watts | 32W |
| Total Input Watts | 40W |
| Lumen Output | 125/W |
| Voltage | 120-277V |
| L70 Expected Life (hours) | 50,000 |
| Listings and Ratings | UL |
