High-Quality LED Troffer Lights

Upgrade your lighting solutions with our premium LED Troffer Lights, perfect for a variety of settings including hotels, offices, retail outlets, restaurants, parking garages, storage rooms, conference rooms, educational facilities, and more. These lights are designed to deliver exceptional performance and long-lasting reliability.

Technical Specifications

Construction: Cold-rolled steel with a 2.6” thickness
Input Voltage: AC120V-277V, 50/60Hz
Power Factor: 0.97
Efficiency: 125 LM/W
Color Rendering Index (CRI): >80
Total Harmonic Distortion (THD): <20
Dimmable: 0~10V dimming capability
IP Rating: IP20 (Indoor Use)
Operating Temperature: -4°F to 122°F
Rated Life: 50,000 hours
Warranty: 5-year warranty

Outstanding Features

Exclusive design lens installs from opening on ends to prevent light leakage
Earthquake hooks integrated into the housing for added safety

Ideal Applications

Perfect one-for-one replacement for conventional fluorescent troffer fixtures

Dimensions

Dimensions: 23-3/4" x 23-3/4" x 2-1/2"

Resources and Downloads

LED Troffer Lights Spec Sheet

Westgate Resources and Downloads

Details

BUG Rating:	B1-U3-G1
CRI:	80
Color Temperature:	3500K\|4000K\|5000K
Compliance & Warranty:	5 Year Warranty\|UL Listed
Country of Origin:	CHINA
Dimming Type:	0-10V
Driver Type:	120-277V
Efficacy:	125LM/W
Finish / Color:	White
Fixture Size:	2X2
Housing Material:	Steel
IP Rating:	IP20
Item Height (Inch):	2.59
Item Length (Inch):	23.74
Item Weight (LBS):	6.77
Item Width (Inch):	23.74
L70 Expected Life (hours):	50,000hr
LED Type:	LED
Lens Material:	Polycarbonate
Light Source:	LED
Lumen Output:	3250\|4000\|5000
Luminaire Efficacy Rating (LER):	125lm/W
Operating Temperature:	-4°F to 122°F
Pack Size:	2
Power Factor:	0.97
Ships From:	CA
Special Features:	Selectable Wattage\|Selectable CCT\|Selectable Lumen Output
THD:	<20%
Voltage:	120-277V
Wattage:	26W\|32W\|40W
