Compact signal booster kit with 0-10 dimming and relay control, featuring Bluetooth Mesh for wireless LED control, 7.87 inches, IP65 and NEMA 4X rated.

Key Features and Benefits

• Bluetooth® SIG mesh technology
• 1 Channel of 0-10 Dimming
• Active High Output for Relay drive
• High-End Trim, Zoning, Continuous Dimming
• Energy Monitoring and Scheduling with optional AleoBlue Gateway
• 5dBi, IP65 Long Range Antenna
• UL Certified Components
• 5-year Limited Warranty

Specifications

• Input Voltage: 12-24 VDC
• Current Consumption: 100mA
• Max Bluetooth Range: 800ft (240m)
• Operating Temp: -30°C to 70°C
• Storage Temp: -40°C to 85°C
• Relative Humidity: 90-95% non-condensing at 30°C
• Enclosure: UL listed to UL 508, NEMA 4X, IP66 rated

Common Uses

Ideal for both interior and exterior environments, enhancing outdoor motion detection and implementing cost-effective, robust Bluetooth mesh control across various applications.
