LED traditional wall pack, 80| 100| 120 watts power selectable, 11,200-16,800 lumens, available in 3000K/ 4000K/ 5000K CCT adjustable, up to 50,000 hours rated life, suitable for wet locations, 5 years limited warranty.
ADVANCED TECHNOLOGY WRAPPED IN A TRADITIONAL FIXTURE
Topaz’s LED Traditional Wall Packs are an easy upgrade to energy efficient lighting, designed to cover the existing footprint of legacy HID fixtures. The integrated dusk-todawn photocell and 0-10V dimming driver provide light adjustability for substantial energy savings. Selectable 3 CCT color and power settings allow up to nine different configurations for added customization while also significantly reducing SKU count.
FEATURES
- Choose from three wattage and three CCT choices for up to nine possible configurations
- Durable aluminum housing with hinged lens frame, captive screws and ½" knockouts on each side
- IK06 impact resistant glass lens
- Semi-cut off light distribution designed to eliminate glare providing smooth, uniform light
- Integrated dusk-to-dawn photocell
SUGGESTED APPLICATIONS
- Commercial and residential
- Security lighting
- Perimeter lighting
- Warehouses
- Condos / apartments
- Hotels
APPLICATIONS
- Input Voltage, Frequency: 120-277V, 50/60Hz
- Power Factor, THD %: >0.9, <25%
- Dimmable: 0-10V down to 15%1
- Efficacy: Up to 140 LPW
- Beam Angle: 90°
- Minimum CRI: 82
- IES Distribution: Type IV
- Functional Life (L70): 50,000 Hours
- Location Rating: Wet
- IP Rating: IP65
- Ambient Operating Temperature: -40°F to 122°F
- Mounting: Wall Mount, typical for mounting heights up to 30'
RESOURCES AND DOWNLOADS
| SKU | TPZ-WP/120W/PCTS/BZ/PC |
|---|---|
| Weight | 8.40 LBS |
| Light Source | LED |
| Fixture Size | - |
| Driver Type | 120-277V, 50/60Hz |
| Lumen Output | 11,200lm-16,800lm |
| Luminaire Efficacy Rating (LER) | Up to 140lm/W |
| Color Rendering Index (CRI) | 82 |
| L70 Expected Life (hours) | 50,000hrs |
| Color Temperature (CCT) | MCT |
| Total Input Watts | 120W |
