Westgate Manufacturing WAE Series LED Economy Wrap-Around Fixture
The Westgate Manufacturing WAE Series LED Economy Wrap-Around Fixture is your go-to lighting solution for industrial, commercial, and residential settings. This top-of-the-line fixture features selectable color temperature, dimming capabilities, an integrated sensor, and an emergency battery backup, ensuring it meets all your modern lighting needs.
Key Features and Benefits
- Selectable Color Temperature: Choose between 3000K, 4000K, or 5000K for versatile lighting.
- Dimming Capabilities: Triac dimming at 120V and 0-10V dimming at 120-277V for personalized ambiance.
- High Lumen Output: Produces 1600 lumens with an efficiency of 80 LPW.
- Long Lifespan: Operates for up to 50,000 hours, reducing maintenance efforts.
- Durability: Constructed from cold-rolled steel with a white powder-coated finish for longevity.
- Integrated Sensor: Equipped with a motion sensor and optional remote control for added convenience.
- Emergency Battery Backup: Provides over 90 minutes of illumination during power outages.
- Easy Installation: Designed for simple ceiling mounting.
Specifications
- Wattage: 20W
- Voltage: 120-277V AC 60Hz
- Power Factor: >0.99
- Lens: Polycarbonate Lens
- Color Rendering Index: CRI ≥ 82
- Operating Temperature: -22°F to 104°F
- Warranty: 5-Year Warranty
Common Uses
Perfect for offices, schools, hallways, retail spaces, and other areas requiring reliable and adjustable lighting solutions.
RESOURCES AND DOWNLOADS
| SKU | WM-WAE-2FT-MCT-DD-EM-SEN |
|---|---|
| Weight | 16.00 LBS |
| Total Input Watts | 20W |
| Color Temperature (CCT) | 3000K |
| Color Temperature (CCT) | 4000K |
| Color Temperature (CCT) | 5000K |
| Voltage | 120-277V |
| Listings and Ratings | ETL |
