The CREA-56-MCTP-BR is a compact outdoor light fixture perfect for general site lighting, residential homes, and doorways. What sets this luminaire apart is its selectable color temperatures (3000K, 4000K, and 5000K) and adjustable lumen outputs (14W, 18W, and 24W). This versatility ensures you get the right lighting for your specific needs.
Key Features and Benefits
- 7-Year Warranty for peace of mind
- 70,000-hour lifespan minimizes maintenance
- Durable die-cast aluminum weatherproof housing and steel backplate
- Available in Dark Bronze or White finish
- Multi-Color Temperature & Multi-Power/Wattage selection
- 120~277V AC voltage compatibility
- High efficacy at 80LM/W
- Dual TRIAC Dimmable and 0-10V Dimmable for flexible lighting control
- Peak total lumens output: 1920LM
- Color rendering index (CRI) > 90 for vibrant color accuracy
- Adjustable beam angles ranging from 10° to 100° up/down
- Wide operating temperature range: -40°F to 104°F
- IP65 rated, ideal for wet locations
Specifications
- Patent-pending design with interchangeable designer trims and different light engines (base)
- Separate engines and trims for a versatile collection at the store level
- Dimensions: 10"(H) x 5 1/2"(W) x 3"(D)
- Power Factor: 0.95
Common Uses
This fixture is excellent for general site lighting, residential houses, and doorways, providing both aesthetic and functional lighting solutions.
RESOURCES AND DOWNLOADS
| SKU | WM-CREA-56-MCTP-BR |
|---|---|
| Weight | 12.00 LBS |
| Total Input Watts | 14W |
| Total Input Watts | 18W |
| Total Input Watts | 24W |
| Lumen Output | 80/W |
| Color Temperature (CCT) | 3000K |
| Color Temperature (CCT) | 4000K |
| Color Temperature (CCT) | 5000K |
| Voltage | 120-277V |
| Color Rendering Index (CRI) | >79 |
| L70 Expected Life (hours) | 50,000 |
| Listings and Ratings | ETL |
