Description

The DLS Series 4-inch Round Disc Lights offer an exceptionally versatile and energy-efficient lighting solution. Operating at only 9 watts but delivering an impressive 540 lumens, these lights boast adjustable color temperatures of 3000K, 4000K, and 5000K, making them perfect for various settings. They are built to last with a rated life of up to 50,000 hours and come with a 5-year limited warranty.

FEATURES

Constructed from durable die-cast aluminum with a powder-coated finish
Unique DOB (Driver On Board) LED technology enclosed in a clear PC cover for enhanced performance in wet locations
Equipped with a closed-cell neoprene foam gasket for better sealing
Multi CCT adjustable via a selectable switch on the LED board under the lens for customized lighting

ELECTRICAL SPECIFICATIONS

Voltage: 120V AC
High power factor: >0.90
Wattage: 9W
Efficacy: 70 lumens per watt

MECHANICAL DESIGN

Sleek white finish
Fits on 4-inch octagonal (4O) or 3-inch octagonal (3O) electrical boxes
Recessed mounting kit included for both recessed and retrofit installations
Operates efficiently in ambient temperatures up to 104°F
5-Year Warranty

LIGHTING PERFORMANCE

White translucent acrylic lens
Advanced DOB LED board enclosed in a clear PC cover for better wet location performance
TRIAC Dimming compatible with standard TRIAC LED dimmers
Total lumens: 630LM
Adjustable color temperatures: 3000K, 4000K, 5000K
High color rendering with CRI ≥ 90
Rated life span: 50,000 hours

APPLICATION

These disc lights are designed to provide flexible lighting solutions for both retrofit and new construction applications. They are ideal for installation in closets, storage areas, attics, corridors, or as general lighting solutions for both residential and commercial environments.

RESOURCES AND DOWNLOADS

DLS Series 4-Inch Round Disc Light Spec Sheet

Westgate Resources and Downloads

Details

BUG Rating:	B0-U1-G1
CRI:	80
Color Temperature:	3000K\|4000K\|5000K
Compliance & Warranty:	Wet Location\|5 Year Warranty\|ETL Listed
Country of Origin:	INDONESIA
Dimming Type:	Phase
Driver Type:	120V
Finish / Color:	White
Fixture Size:	Other
Housing Material:	Aluminum
Item Height (Inch):	1
Item Length (Inch):	5.12
Item Weight (LBS):	0.585
Item Width (Inch):	5.12
L70 Expected Life (hours):	50,000hr
LED Type:	Unique DOB (Driver On Board)
Lens Material:	White translucent acrylic lens
Light Source:	LED
Lumen Output:	540
Operating Temperature:	104°F MAX
Power Factor:	0.9
Ships From:	CA
Special Features:	Selectable CCT
Voltage:	120V
Wattage:	9W
