LHS1, Power Selectable 320W, Field Color Selectable 4000K/5000K, 0-10V Dimming

Versatile Linear High Bay with selectable 4000K/5000K color temperature and adjustable lumen output up to 48,000 lumens.

Key Features and Benefits

• Power & Color Select Technology for simplified SKU management and field customization.
• PowerSET – 4 Power settings.
• FieldCCeT – 2 CCT settings (4000K/5000K).
• Full spectrum input voltage coverage: 120-347V.
• Wide range of lumen packages (7,500 – 66,000 lumens) provide solutions for mounting heights up to 60’.
• Diffused polycarbonate lens for reduced glare (beam angle 95°).
• Heavy gauge steel housing and impact resistant lens for robust and reliable installation.
• Technical performance: CRI >80, Efficacy up to 150 LPW, Lumen Maintenance 70% (L70) at >100,000Hrs, THD <20%, Power Factor >0.9, Surge Protection: 6kV included.
• All products are DesignLights Consortium® (DLC) Premium listed.

Specifications

• Selectable color temperature: 4000K/5000K.
• Lumen output: 48,000/45,000/42,000/39,000 lumens.
• Input voltage: 120-347V.
• CRI: >80.
• Efficacy: Up to 150 LPW.
• Lifespan: >100,000 hours (L70).
• Surge Protection: 6kV included.

Common Uses

Warehouses, Distribution Centers, Grocery Stores, Gymnasiums, Data Centers, Manufacturing Plants, Cold Storage, Big Box Retail, Indoor Recreational Facilities, Vehicle Maintenance Facilities.
