LHS1, Power Selectable 320W, Field Color Selectable 4000K/5000K, 0-10V Dimming

By Eiko Global
LHS1, Power Selectable 320W, Field Color Selectable 4000K/5000K, 0-10V Dimming

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

LHS1, Power Selectable 320W, Field Color Selectable 4000K/5000K, 0-10V Dimming

$207.70
  • SKU: E-LHS1-PS320-8FCCT-HDIM
  • MPN: LHS1-PS320-8FCCT-HDIM

Quick Overview

Versatile Linear High Bay with selectable 4000K/5000K color temperature and adjustable lumen output up to 48,000 lumens.

In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

Versatile Linear High Bay with selectable 4000K/5000K color temperature and adjustable lumen output up to 48,000 lumens.

Key Features and Benefits

  • Power & Color Select Technology for simplified SKU management and field customization.
  • PowerSET – 4 Power settings.
  • FieldCCeT – 2 CCT settings (4000K/5000K).
  • Full spectrum input voltage coverage: 120-347V.
  • Wide range of lumen packages (7,500 – 66,000 lumens) provide solutions for mounting heights up to 60’.
  • Diffused polycarbonate lens for reduced glare (beam angle 95°).
  • Heavy gauge steel housing and impact resistant lens for robust and reliable installation.
  • Technical performance: CRI >80, Efficacy up to 150 LPW, Lumen Maintenance 70% (L70) at >100,000Hrs, THD <20%, Power Factor >0.9, Surge Protection: 6kV included.
  • All products are DesignLights Consortium® (DLC) Premium listed.

Specifications

  • Selectable color temperature: 4000K/5000K.
  • Lumen output: 48,000/45,000/42,000/39,000 lumens.
  • Input voltage: 120-347V.
  • CRI: >80.
  • Efficacy: Up to 150 LPW.
  • Lifespan: >100,000 hours (L70).
  • Surge Protection: 6kV included.

Common Uses

Warehouses, Distribution Centers, Grocery Stores, Gymnasiums, Data Centers, Manufacturing Plants, Cold Storage, Big Box Retail, Indoor Recreational Facilities, Vehicle Maintenance Facilities.

RESOURCES AND DOWNLOADS

LHS1 Spec Sheet
