New Generation UFO Highbay - Versatile and Efficient
Experience unparalleled energy efficiency and adaptability with the new generation UFO highbay. Our product boasts a power selectable design, offering 50W, 80W, 100W, and 150W settings. With a lumen output range from 6,250 to 18,750, it ensures the perfect lighting condition for various applications – whether in warehouses, pathways, or loading docks.
Features
- Waterproof design suitable for wet locations.
- Constructed with ADC12 Aluminum Heat Sink with Outdoor Powder Coating Finish.
- Optical Lens made from PC materials ensuring high light transmittance, anti-UV, and fire resistance.
- Multi color temperature & multi power selectable via switch on driver housing.
Electrical Specifications
- Input Wattage: Selectable 50W/80W/100W/150W.
- Input Voltage: 120-277VAC 50/60Hz.
- Power Factor: >0.9.
- Total Harmonic Distortion (THD): <20%.
- Efficacy: 125 lumens per watt (LPW).
Mechanical Specifications
- ADC12 Aluminum Heat Sink with an outdoor powder coating finish.
- Optical Lens built from PC materials for durability and high light transmittance.
- Utilizes LUMILEDS 2835 LEDs.
- Waterproof and aging-resistant LED PCB board with high conductivity.
- Operating Temperature: -40°F to 122°F.
- IP Rating: IP65 for wet locations.
- Includes a 5-Year Warranty.
Lighting Specifications
- Dimming Range: 0~10V.
- Total Lumens: 6250/10000/12500/18750 LM.
- Selectable Color Temperatures: 3000K/4000K/5000K/5700K.
- Color Rendering Index (CRI): > 80.
- Beam Angle: 90°.
- Lifespan: Up to 50,000 hours.
Applications
- Ideal for general site lighting, alleys, loading docks, doorways, pathways, parking areas, warehouses, and storage buildings.
Resources and Downloads
New Generation UFO Highbay, 50W-150W Power and CCT's Spec Sheet
| SKU | WM-UHX-150W-MCTP-WH |
|---|---|
| Weight | 13.00 LBS |
| Light Source | LED |
| Fixture Size | Other |
| Color Rendering Index (CRI) | >80 |
| Luminaire Efficacy Rating (LER) | 125lm/W |
| Lumen Output | 6,250lm-18,750lm |
| L70 Expected Life (hours) | 50,000 hrs |
| Driver Type | 120-277VAC 50/60Hz |
| Color Temperature (CCT) | MCT |
| Total Input Watts | 50W/80W/100W/150W |
| Total Input Watts | 50W |
| Total Input Watts | 80W |
| Total Input Watts | 100W |
| Total Input Watts | 150W |
| Lumen Output | 125/W |
| Color Temperature (CCT) | 3000K |
| Color Temperature (CCT) | 4000K |
| Color Temperature (CCT) | 5000K |
| Color Temperature (CCT) | 5700K |
| Voltage | 120-277V |
| L70 Expected Life (hours) | 50,000 |
| Listings and Ratings | UL, DLC |
