Introducing the New Generation UFO Highbay Light
Discover the cutting-edge UFO Highbay light, designed for exceptional performance in a wide range of environments. This powerful lighting solution offers selectable wattages of 50W, 80W, 100W, and 150W, delivering an impressive light output of 6,250 to 18,750 lumens. With adjustable color temperatures of 3000K, 4000K, 5000K, and 5700K, you can tailor the lighting to perfectly suit your needs.
Features
- Waterproof design, suitable for wet locations
- ADC12 Aluminum Heat Sink with an Outdoor Powder Coating Finish
- High Light Transmittance PC Materials Optical Lens, Anti-UV, and Fire-Resistant
- Multi Color Temperature and Multi Power Selectable via Switch on Driver Housing
Electrical Specifications
- Input Wattage: 50W / 80W / 100W / 150W
- Input Voltage: 120-277V 50 / 60Hz
- Power Factor: > 0.9
- Total Harmonic Distortion (THD): < 20%
- Efficacy: 125 lumens per watt (LPW)
Mechanical Details
- ADC12 Aluminum Heat Sink with Outdoor Powder Coating Finish
- PC Materials Optical Lens: High Light Transmittance, Anti-UV, and Fire-Resistant
- LED Type: LUMILEDS 2835
- LED PCB Board: High Conductive, Waterproof, Aging Resistance, Salt Mist Resistance for Long Lifespan
- Operating Temperature: -40°F to 122°F
- IP Rating: IP65, suitable for Wet Locations
- 5-Year Warranty included
Lighting Specifications
- Dimming: 0-10V
- Total Lumens: 6,250 / 10,000 / 12,500 / 18,750
- Color Temperatures: 3000K / 4000K / 5000K / 5700K
- Color Rendering Index (CRI): > 80
- Beam Angle: 90°
- Rated Lifespan: 50,000 hours
Applications
- Ideal for general site lighting, alleys, loading docks, doorways, pathways, parking areas, warehouses, and storage buildings
Resources and Downloads
New Gen. UFO Highbay 50W-150W Power and CCT Adjustable Spec Sheet
| SKU | WM-UHX-150W-MCTP |
|---|---|
| Weight | 13.00 LBS |
| Light Source | LED |
| Fixture Size | Other |
| Color Rendering Index (CRI) | >80 |
| Luminaire Efficacy Rating (LER) | 125lm/W |
| Lumen Output | 6,250lm-18,750lm |
| L70 Expected Life (hours) | 50,000 hrs |
| Driver Type | 120-277V 50/60Hz |
| Color Temperature (CCT) | MCT |
| Total Input Watts | 50W/80W/100W/150W |
| Total Input Watts | 50W |
| Total Input Watts | 80W |
| Total Input Watts | 100W |
| Total Input Watts | 150W |
| Lumen Output | 125/W |
| Color Temperature (CCT) | 3000K |
| Color Temperature (CCT) | 4000K |
| Color Temperature (CCT) | 5000K |
| Color Temperature (CCT) | 5700K |
| Voltage | 120-277V |
| L70 Expected Life (hours) | 50,000 |
| Listings and Ratings | UL, DLC |
