12-inch round high performance disk residential LED lighting, 30 watts, 1,800 lumens, available in 3000K/ 4000K/ 5000K CCT adjustable, white finish, up to 50,000 hours rated life, 5 years limited warranty.
FEATURES
- Die-cast Aluminum. Powder-Coated
- Unique DOB (Driver On Board) LED Board Enclosed in Clear PC Cover for Better Wet Location Performance
- Closed Cell Neoprene Foam Gasket
- Multi CCT (Selectable Switch on LED Board Under the Lens)
ELECTRICAL
- Voltage: 277V AC
- Power Factor: >0.90
- Wattage: 30W
- Efficacy: 70 LPW
MECHANICAL
- White Finish
- Die-cast Aluminum. Powder-Coated
- Gasket: Closed Cell Neoprene Foam Gasket
- Fits on 4”Octagonal (4O) or 3”Octagonal (3O) Electrical Boxes
- Recessed Mounting Kit Included for Recessed/Retrofit Installation
- Maximum Ambient Temperature: 104°F
- 5-Year Warranty
LIGHTING
- Lens: White Translucent Acrylic
- LED: Unique DOB (Driver On Board) LED Board Enclosed in Clear PC Cover for Better Wet Location Performance
- Total Lumens: 1800LM
- Color Temperatures: 3000K/ 4000K/ 5000K
- Multi CCT (Selectable Switch on LED Board Under the Lens)
- Color Rendering Index: CRI ≥ 90
- Rated life: 50,000 hrs
APPLICATIONS
- Disk lights have been designed to be a flexible lighting solution for retrofit and new construction applications, Ideal for closets, storage areas, attics, corridors or general lighting solutions for residential and commercial applications.
RESOURCES AND DOWNLOADS
12" Round High Performance Disk LED Light - CCT's Spec Sheet
| SKU | WM-DLS12-MCT-277V |
|---|---|
| Weight | 12.00 LBS |
| Light Source | LED |
| Fixture Size | 12" |
| Driver Type | 277V |
| Lumen Output | 1,800lm |
| Color Rendering Index (CRI) | ≥90 |
| L70 Expected Life (hours) | 50,000hrs |
| Color Temperature (CCT) | MCT |
| Total Input Watts | 30 |
