The WM-LPS-S8 LED Surface Mount Panel, available at relightdepot.com, is a versatile lighting solution perfect for various applications such as hotels, offices, retail outlets, restaurants, parking garages, storage rooms, conference rooms, and educational facilities. This energy-efficient 16W panel is designed to provide superior illumination and longevity.
ELECTRICAL SPECIFICATIONS
- Voltage: 120-277VAC 50/60Hz
- Wattage: 16W
- Power factor: >0.95
- Efficacy: 80LM/W
HOUSING SPECIFICATIONS
- Finish: White surface mount panel
- Driver: External
- Operating temperature: -13°F ~ 104°F
- Lifespan: 50,000 hrs.
- Environment: Suitable for Damp Locations
LIGHTING SPECIFICATIONS
- Dimming: 120V AC input with TRIAC dimming, 100-277V AC input NON-dimmable
- Recommended Dimmers: DVCL-153P, MSCL-OP153M, CTCL-153P
- Total lumens: 1280LM
- Color temperature: 5000K/4000K/3000K
- Color rendering index: >90
RESOURCES AND DOWNLOADS
| SKU | WM-LPS-S8 |
|---|---|
| Weight | 8.00 LBS |
| Light Source | LED |
| Fixture Size | 8" Square |
| Color Rendering Index (CRI) | >90 |
| Driver Type | 120-277VAC |
| Lumen Output | 1280 lm |
| Luminaire Efficacy Rating (LER) | -13°F~104°F |
| L70 Expected Life (hours) | 50,000 hrs |
| Color Temperature (CCT) | 5000K |
| Color Temperature (CCT) | 4000K |
| Color Temperature (CCT) | 3000K |
| Total Input Watts | 16 |
| Total Input Watts | 16W |
| Lumen Output | 1280 |
| Voltage | 120VAC |
| Color Rendering Index (CRI) | >80 |
| L70 Expected Life (hours) | 50,000 |
| Listings and Ratings | UL |
