The perfect solution for upgrading your existing site lighting, ideal for replacing outdated HID and fluorescent systems. This versatile lighting fixture is perfect for alleys, loading docks, doorways, pathways, and parking areas.
ELECTRICAL SPECIFICATIONS
- Voltage: 100~277 VAC /60 Hz
- Wattage: 20 W
- Power factor: 0.90
- Efficacy: 96 LM/W
HOUSING SPECIFICATIONS
- Constructed with high-quality ADC12 aluminum for superior heat dissipation
- Durable outdoor powder coating
- Vandal resistant housing
- Operational temperature range: -40°F to 104°F
- Estimated lifespan: 70,000 hours
- IP Rating: IP64
CERTIFICATIONSUL, DLC
DIMENSIONS11.4"(L) x 4.5"(W) x 3.5"(H)
LIGHTING SPECIFICATIONS
- Equipped with an optical lens
- Total lumens: 1920 LM
- Available color temperatures: 5000K/4000K/3000K
- Color rendering index: >70
WARRANTY7 years
RESOURCES AND DOWNLOADS
| SKU | WM-WMV-20W |
|---|---|
| Weight | 12.00 LBS |
| Light Source | LED |
| Fixture Size | Other |
| Color Rendering Index (CRI) | >70 |
| Driver Type | 100~277 VAC |
| Lumen Output | 1920 lm |
| L70 Expected Life (hours) | 70,000 hrs |
| Color Temperature (CCT) | 3000K |
| Color Temperature (CCT) | 4000K |
| Color Temperature (CCT) | 5000K |
| Total Input Watts | 20 |
| Total Input Watts | 20W |
| Lumen Output | 1800 |
| Voltage | 120-277V |
| L70 Expected Life (hours) | 70,000 |
| Listings and Ratings | UL |
| Lumen Output | 1900 |
| Lumen Output | 2000 |
