Energetic Lighting ESB LED Area Light, 40000 lumens, 300W, 100-277V, 5000K, 80 CRI, Type III-M, Bronze, 0-10V Dimmable, Large Housing

By Energetic Lighting
Energetic Lighting ESB LED Area Light, 40000 lumens, 300W, 100-277V, 5000K, 80 CRI, Type III-M, Bronze, 0-10V Dimmable, Large Housing

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Energetic Lighting ESB LED Area Light, 40000 lumens, 300W, 100-277V, 5000K, 80 CRI, Type III-M, Bronze, 0-10V Dimmable, Large Housing

$218.10
  • SKU: ELI-ESB-M400E850C3
  • MPN: ESB-M400E850C3

Quick Overview

High-output LED shoebox area light for parking lots and site lighting, delivering 40000 lumens at 300W (130 lm/W) with 100-277V input, 5000K CCT, Type III-M distribution, IP65 wet-location rating, and 0-10V dimming.

UL Listed
WET RATED
WARRANTY 5 YEARS
IP65
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Energetic Lighting ESB series is a performance-driven LED area light family designed to modernize traditional shoebox installations with a slimmer, self-cleaning profile. This ESB-M400E850C3 configuration delivers powerful illumination for demanding outdoor applications while maintaining strong efficiency and long-term reliability.

Key Features and Benefits

  • Delivers high-lumen output for large parking and perimeter zones with reduced fixture count.
  • IP65 construction supports dependable operation in wet outdoor environments.
  • 0-10V dimming capability enables energy savings and lighting control flexibility.
  • Full cut-off optical design helps reduce glare and improve visual comfort.
  • Backed by a 5-year limited warranty for added project confidence.
  • UL certified and RoHS compliant for safety and environmental alignment.

Specifications

  • Lumen Output: 40000
  • Wattage: 300W
  • Voltage: 100-277V
  • Color Temperature: 5000K
  • CRI: 80
  • Efficacy: 130 lm/W
  • Distribution Type: Type III
  • BUG Rating: B3-U2-G4
  • Power Factor: 0.9
  • THD: 20
  • Frequency: 50/60 Hz
  • Max Ambient Temperature: 45°C (113°F)
  • Rated Life (L70): 54000 hours
  • Finish: Bronze
  • Ingress Protection: IP65
  • Surge Protection: 6kV

Common Uses

Ideal for parking lots, general area lighting, security perimeters, wall washing, and landscape-adjacent commercial outdoor spaces requiring high-output, uniform illumination.

RESOURCES AND DOWNLOADS

Energetic Lighting ESB LED Area Light Spec Sheet
