ESL Round Canopy, Round, 60W|80W|100W, 3000K|4000K|5000K, White

By ESL Vision

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

ESL Round Canopy, Round, 60W|80W|100W, 3000K|4000K|5000K, White

$156.60
  • SKU: ESL-ESL-CP-R-60100W-13050
  • MPN: ESL-CP-R-60100W-13050

Quick Overview

Selectable round LED canopy light with 60W/80W/100W and 3000K/4000K/5000K settings, delivering up to 16,500 lumens at 165 lm/W. Ideal for canopies, parking structures, and covered exterior areas.

UL Listed
WET RATED
WARRANTY 5 YEARS
IP65
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The ESL Round Canopy Series is a versatile surface-mount lighting solution designed for commercial exterior and semi-exterior applications. This 1st generation round canopy model combines field-selectable wattage and CCT in one fixture, helping contractors and facility teams simplify inventory while matching site requirements. Built for dependable performance, it delivers high output, strong efficacy, and long service life for demanding canopy environments.

Key Features and Benefits

  • Multi-watt selectable operation (60W/80W/100W) for flexible light levels from one SKU
  • 3-CCT selectable output (3000K/4000K/5000K) to tune visual comfort and site appearance
  • 0-10V dimming to off for energy savings and lighting control integration
  • High-performance output up to 16,500 lumens with efficacy up to 165 lm/W
  • Long 175,000-hour L70 life reduces maintenance cycles in hard-to-service locations
  • DLC Premium listed and UL certified with 5-year warranty support

Specifications

  • Lumen Output: up to 16,500
  • Input Voltage: 120-277V
  • Frequency: 50/60Hz
  • CRI: >80
  • Beam Angle: 150°
  • Power Factor: >0.9
  • THD: <20%
  • Surge Protection: 6kV
  • Operating Temperature: -22°F to 113°F (-30°C to 45°C)
  • Dimensions: Ø11.02" x 3.11"
  • Weight: 4.93 lbs
  • Default Setting: 100W, 4000K

Common Uses

Ideal for gas station canopies, parking garages, covered walkways, loading zones, and other commercial soffit or overhang applications where durable, efficient, and selectable area lighting is required.

RESOURCES AND DOWNLOADS

ESL Round Canopy Spec Sheet
