Introducing the LVTE-2FT-15-25W-MCTP: Advanced Linear Vapor-Tight Fixture

Elevate your lighting with the LVTE-2FT-15-25W-MCTP from our leading Builder Series. This state-of-the-art linear vapor-tight fixture has been engineered to meet the demanding needs of various industrial and commercial environments. Featuring selectable wattages and color temperatures, this fixture offers unparalleled flexibility, durability, and energy efficiency.

Key Features and Benefits

Wattage Selectable: Customize your lighting intensity with options of 15W, 17W, 20W, or 25W.
CCT Selectable: Choose from 3000K, 4000K, or 5000K for mood or task-specific lighting.
High Efficiency: Enjoy up to 140 lumens per watt for bright and cost-effective illumination.
Durable Construction: Ideal for harsh conditions, ensuring long-lasting performance.
Extended Lifespan: Reduces the need for frequent replacements and maintenance.

Technical Specifications

Model: LVTE-2FT-15-25W-MCTP
Size: 2ft
Wattage: 15W/17W/20W/25W (Selectable)
Luminous Efficiency: Up to 140LM/W
Color Temperatures: 3000K/4000K/5000K (Selectable)
Rating: Vapor-tight, suitable for challenging environments

Common Uses

The LVTE-2FT-15-25W-MCTP is perfect for areas that demand robust and efficient lighting solutions, such as warehouses, manufacturing facilities, and outdoor covered areas. Its selectable wattage and CCT make it the ideal choice for a variety of lighting scenarios.

RESOURCES AND DOWNLOADS

2Ft. Builder Series Linear Vapor-Tight Fixture Spec Sheet

Westgate Resources and Downloads

Details

CRI:	80
Color Temperature:	3500K\|4000K\|5000K
Compliance & Warranty:	5 Year Warranty\|ETL Listed
Country of Origin:	CAMBODIA
Dimming Type:	0-10V
Efficacy:	140LM/W
Finish / Color:	White\|Gray
Housing Material:	Polycarbonate
IP Rating:	IP66
Item Height (Inch):	3.4
Item Length (Inch):	25.59
Item Weight (LBS):	2.4200000000000004
Item Width (Inch):	4.17
L70 Expected Life (hours):	50,000hr
LED Type:	SEOUL 3525
Lens Material:	PC
Lumen Output:	2100\|2380\|2800\|3500
Operating Temperature:	一25.6°F to 104°F
Power Factor:	>0.9
Ships From:	CA
Special Features:	Selectable Wattage\|Selectable CCT\|Selectable Lumen Output\|NSF Rated
THD:	<20%
Voltage:	120-277V
Wattage:	15W\|17W\|20W\|25W
