2'X2' LED dual lens troffer light, 25W-35W power selectable, 3,150-4,375 lumens, available in 3500K/ 4000K/ 5000K CCT adjustable, polycarbonate lens, up to 50,000 hours rated life, 5 years limited warranty.
Ideal for both new construction and remodel/replacement of fluorescent troffers in commercial office spaces, schools, healthcare facilities and retail merchandising areas.
FEATURES
- High Quality LED Chips Provide High Efficiency, Heat Dissipation, Stability, and Lumen Maintenance
- 5-Year Warranty
- 50,000 Hours Rated Life
- Lens: Polycarbonate
- Multi CCT: Selectable Multi-CCT & Power Switches Inside The Driver Box
ELECTRICAL
- Voltage: 120-277VAC 50/60Hz
- Wattage: 25W/ 30W/ 35W
- Power Factor: >0.92
- Efficacy: 125 LPW
MECHANICAL
- High Quality LED Chips Provide High Efficiency, Heat Dissipation, Stability, and Lumen Maintenance
- Individual, Pure Aluminum Heat Sinks Offers Heat Transmission Faster Than Die Cast Steel
- Driver disconnect provided where required to comply with US and Canadian codes
- Performance Engineered Optical Lens Assembly Delivers Unique Beam Angles and Reduces Glare
- Polycarbonate Lens
- Operating Temp: -22°F to 104°F
LIGHTING
- Dimmable: 0~10V Dimming
- Total Lumens: 3150LM/ 3750LM/ 4375LM
- Multi CCT: Selectable Multi-CCT & Power Switches Inside The Driver Box
- Color Temperatures: 3500K/4000K/5000K
- Color Rendering Index: CRI ≥ 80
- IP Rating: IP20 Indoor use only
APPLICATIONS
- Retail/Schools/Offices
- Healthcare/Conference rooms
- Hospitality/Corridors
- Reception areas/Foyer
- Library
RESOURCES AND DOWNLOADS
| SKU | WM-LTRD-2X2-MCTP |
|---|---|
| Weight | 24.00 LBS |
| Light Source | T8 Fluorescent |
| Fixture Size | - |
| Color Rendering Index (CRI) | ≥ 80 |
| Driver Type | 120-277VAC |
| Lumen Output | 3150LM/ 3750LM/ 4375LM |
| Luminaire Efficacy Rating (LER) | 125lm/w |
| L70 Expected Life (hours) | 50,000hrs |
| Color Temperature (CCT) | 3500K/4000K/5000K |
| Total Input Watts | 25W/ 30W/ 35W |
