Name: 8Ft. 80 Watt Narrow Strip Light with Sensor, Multi Color Temperature & Power
Brand: Westgate Manufacturing
SKU: WM-LSN-8FT-80W-MCTP-D-SEN
Price: 140.74 USD
Availability: InStock

Description

Details

Warranty

Delivery & Returns

Description

Westgate LSN Series 8ft Narrow Strip Light

The LSN Series 8ft Narrow Strip Light by Westgate Manufacturing is a versatile and energy-efficient lighting solution that's perfect for both commercial and residential applications. This model comes equipped with a selectable multi-color temperature and power switch inside the fixture, making it adaptable to various lighting needs. It is also dimmable with a 0~10V dimming sensor for optimal control over brightness.

Key Features and Benefits

High Lumen Efficiency
Multi-Color Temperature & Power (Selectable Switch Inside Fixture)
0~10V Dimmable
Energy-efficient, reducing energy consumption by up to 80% compared to fluorescent fixtures
Long-lasting performance with a rated life of 50,000 hours
Bi-Level Microwave Motion Sensor for enhanced security
Indoor Use Only (IP20 Rating)
5-Year Warranty for peace of mind

Technical Specifications

Voltage: 120-277VAC 60Hz
Wattage: 80W
Total Lumens: 10400LM
Color Temperatures: 3500K/4000K/5000K
Color Rendering Index: CRI ≥ 80
Mounting Height: Up to 25 feet
Operating Temperature: -4°F - 122°F
Durable Cold-rolled Steel Housing
Frosted Polycarbonate Lens

Common Uses

Perfect for a variety of settings, the LSN Series 8ft Narrow Strip Light is ideal for corridors, stairwells, public rooms, schools, hospitals, utility areas, and many other applications. Its versatile design also makes it suitable for residential, commercial, and industrial lighting needs, especially in areas requiring motion sensors or battery backups.

Resources and Downloads

Narrow Strip Light with Sensor Spec Sheet

Westgate Resources and Downloads

Details

Beam Angle:	130°
CRI:	80
Color Temperature:	3500K\|4000K\|5000K
Compliance & Warranty:	5 Year Warranty\|UL Listed
Country of Origin:	VIETNAM
Dimming Type:	0-10V
Efficacy:	130LM/W
Finish / Color:	White
Housing Material:	Polycarbonate
IP Rating:	IP40
Item Height (Inch):	3.26
Item Length (Inch):	95.98
Item Weight (LBS):	5.74
Item Width (Inch):	2.95
L70 Expected Life (hours):	50,000hr
LED Type:	SMD2835 LED
Lens Material:	Polycarbonate Lens
Lumen Output:	10400\|6500\|8320
Operating Temperature:	-4°F to 113°F
Power Factor:	>0.90
Ships From:	CA
Special Features:	Selectable Wattage\|Selectable CCT\|Selectable Lumen Output
THD:	<20%
Voltage:	120-277V
Wattage:	50W\|64W\|80W
