ATG Skyline G4 Linear High Bay, 2.6FT, 270W/230W/200W, 4000K/5000K Selectable, Frosted Lens, 95°x95°, 120-277V

By ATG Electronics

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

ATG Skyline G4 Linear High Bay, 2.6FT, 270W/230W/200W, 4000K/5000K Selectable, Frosted Lens, 95°x95°, 120-277V

$204.40
  • SKU: ATG-HBELD-270P-T1F-S-G4
  • MPN: HBELD-270P-T1F-S-G4

Quick Overview

Power and CCT selectable 2.6' linear high bay with 270W/230W/200W settings, 4000K/5000K options, 0-10V dimming, and up to 39,531 lumens for warehouses, industrial aisles, and commercial high-ceiling spaces.

UL Listed
DLC Premium
Title 24 Compliant
DAMP RATED
WARRANTY 10 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The ATG Skyline G4 series is a versatile linear high bay family designed for modern industrial and commercial facilities that need adaptable output and color tuning. This 2.6' configuration delivers high lumen performance with selectable wattage and CCT, making it a practical choice for retrofit and new construction projects.

Key Features and Benefits

  • Selectable power settings (270W/230W/200W) let you fine-tune light levels and energy use on site.
  • Dual CCT selection (4000K/5000K) supports both neutral and daylight-style lighting preferences.
  • Frosted lens and 95°x95° distribution help reduce glare while maintaining broad, uniform coverage.
  • 0-10V dimming compatibility enables smooth control integration for additional energy savings.
  • DLC Premium listed and UL 1598 suitable for damp locations for code-friendly commercial deployment.
  • Backed by a 10-year warranty for long-term reliability and lower maintenance risk.

Specifications

  • Lumen Output: 30,933|34,670|38,509|31,257|35,238|39,531
  • Voltage: 120-277V
  • CRI: >80
  • Efficacy: 151|155|159|160 lm/W
  • Beam Angle: 95°x95°
  • Power Factor: >0.9
  • THD: <20
  • Surge Protection: 6kV
  • Dimensions: 31.1" L x 10.2" W x 1.77" D
  • Rated Life (L70): 134,000 hours

Common Uses

Ideal for warehouses, distribution centers, manufacturing areas, gymnasiums, big-box retail, and other high-mount applications requiring efficient, controllable, and uniform linear high bay illumination.
