Introducing the Builder Series 40W-80W Flat Wall Pack

Enhance the security and ambiance of your exteriors with our Builder Series 40W-80W Flat Wall Pack. This advanced lighting solution is designed to meet the diverse needs of modern outdoor environments, offering high efficiency, adjustable color temperatures, and robust security features.

Key Features and Benefits

Versatile Power Options: Choose from 40W, 60W, and 80W settings to match your lighting needs.
High Efficiency: Achieves an impressive 130 lumens per watt, providing bright and cost-effective illumination.
Adjustable Color Temperatures: Easily switch between 3000K, 4000K, and 5000K to customize your lighting atmosphere.
Durability: The glass lens and die-cast aluminum construction ensure long-lasting performance and resilience.
Enhanced Security: Vandal-resistant screws and a hardened exterior protect against tampering and harsh weather conditions.
Automated Lighting Control: A built-in photocell allows for automated dusk-to-dawn lighting, boosting convenience and energy savings.

Specifications

Voltage: 120-277V AC 60Hz
Wattage: 40W, 60W, 80W
Power Factor: >0.9
THD: <20%
Efficacy: 130 LPW
Lens: High light transmittance, anti-UV, and fire-resistant PC lens
Maximum Lumens: 10400LM
Color Rendering Index: CRI ≥ 80
Beam Angle: H127° x V85°
Rated Life: 70,000 hours
Operating Temperature: -40°F to 113°F
Wet Location Rated: Yes
IP Rating: IP65
Warranty: 7-year warranty

Common Uses

Ideal for general site lighting, alleys, loading docks, doorways, pathways, and parking areas, the Builder Series Flat Wall Pack is perfect for any outdoor location requiring reliable, efficient, and secure lighting. It works seamlessly with motion sensors or other instant on/off controls.

RESOURCES AND DOWNLOADS

Builder Series 40W-80W Flat Wall Pack Spec Sheet

Details

BUG Rating:	B2-U2-G2
Beam Angle:	H127*V85°
CRI:	80
Color Temperature:	3000K\|4000K\|5000K
Compliance & Warranty:	7 Year Warranty\|DLC Premium\|UL Listed
Country of Origin:	VIETNAM
Dimming Type:	0-10V
Efficacy:	130LM/W
Finish / Color:	Bronze
Housing Material:	Aluminum
IP Rating:	IP65
Item Height (Inch):	4.45
Item Length (Inch):	9.84
Item Weight (LBS):	7.27
Item Width (Inch):	8.86
L70 Expected Life (hours):	50000hrs
Lumen Output:	5200\|7800\|10400
Operating Temperature:	-40℃ TO 45℃, -25℃ TO 45℃
Power Factor:	>0.9
Ships From:	CA
Special Features:	Selectable Wattage\|Selectable CCT\|Selectable Lumen Output
THD:	<20%
Voltage:	120-277V
Wattage:	40W\|60W\|80W
