3" Ceiling Mount Cylinder, 5/7/9W, 3/4/5K, TRIAC & 0-10V Dimming, Black, C & F Lenses Incl

By Westgate Manufacturing

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

3" Ceiling Mount Cylinder, 5/7/9W, 3/4/5K, TRIAC & 0-10V Dimming, Black, C & F Lenses Incl

$99.74
MSRP: $112.78
You save $ 13.04 (12%)
  • SKU: WM-CMC3-MCTP-DD
  • MPN: CMC3-MCTP-DD

Quick Overview

3" Ceiling Mount Cylinder, 5/7/9W, 3/4/5K, TRIAC & 0-10V Dimming, Black, C & F Lenses Incl (wattage: 5W/7W/9W; lumens: 75LM/W; efficacy: 75LM/W; CCT: 30K/40K/50K; voltage: 120-277V)

IP20
Availability: 1 business day
In Stock & Ready To Ship!
Current Stock:Only left:
Free shipping on this item
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

Product Overview

The 3-inch Architectural Ceiling & Suspended Cylinders offer a versatile lighting solution for various architectural applications. With selectable wattage options of 5W, 7W, and 9W, this fixture delivers between 375 and 675 lumens. It also provides adjustable color temperatures ranging from 3000K to 5000K, making it adaptable to different ambient needs. Boasting an impressive rated life of up to 70,000 hours and a 7-year warranty, this light guarantees long-term reliability and performance.

Design and Construction

This 3-inch Cylinder Light features a sleek aluminum body with a white finish and a clear glass lens. It's available in pendant and ceiling configurations, making it suitable for various installation types. The aluminum housing and polycarbonate (PC) lens ensure durability and long-lasting performance.

Features

  • Selectable Multi-CCT & Power Switches on the back of the fixture (Dual Function)
  • Dimmable through Triac at 120V and 0-10V Dimming at 120-277V
  • Robust 7-Year Warranty for peace of mind
  • Aluminum base and polycarbonate lens for durability

Electrical Specifications

  • Voltage: 120-277V
  • High Power Factor: >0.90
  • Low Total Harmonic Distortion: <20%
  • Wattage Options: 5W, 7W, 9W
  • Efficacy: 75 lumens per watt

Mechanical Features

  • Constructed with Aluminum Housing and PC lens
  • Operational Temperature: -13ºF to 113ºF
  • IP Rating: IP40, suitable for damp locations
  • Rated Life: Up to 70,000 hours

Lighting Specifications

  • Dimmability: Triac Dimmable at 120V & 0-10V Dimming at 120-277V
  • Total Lumens: 675 Lumens
  • Color Temperatures: Adjustable 3000K, 4000K, 5000K
  • Color Rendering Index (CRI): ≥ 80
  • Beam Angle: 25°

Applications

  • Ideal for architectural ceiling and suspended lighting solutions
  • Suitable for both commercial and residential settings
