Universal Light Bar Kit, 4', 3500K|5000K, 120-277V, 1 Light Bar

By Green Creative

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Universal Light Bar Kit, 4', 3500K|5000K, 120-277V, 1 Light Bar

$47.65
  • SKU: GC-40LB/4F/8/U/A1
  • MPN: 40LB/4F/8/U/A1

Quick Overview

4' LED retrofit light bar kit for enclosed and damp fixtures, featuring selectable lumen output, 3500K/5000K CCT options, 120-277V input, up to 163 lm/W efficacy, and 0-10V dimming.

ETL Listed
DLC Standard
DAMP RATED
WARRANTY 5 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Universal Light Bar Kit from Green Creative is a flexible linear retrofit solution designed to modernize existing fluorescent fixtures with efficient LED performance. Built for fast installation, this 4' one-bar configuration combines selectable output, broad voltage compatibility, and durable lightweight construction. It is a key option in the lineup for cost-effective upgrades in commercial and industrial spaces.

Key Features and Benefits

  • Field-selectable lumen settings let you tune light levels for different application needs.
  • Quick connectors and magnetic mounting points help reduce installation time and labor.
  • Durable plastic housing with frosted polycarbonate lens delivers lightweight, reliable performance.
  • 0-10V dimming capability supports energy savings and improved lighting control.
  • Suitable for enclosed fixtures and damp locations for broader retrofit versatility.
  • Backed by a 5-year limited warranty
  • DLC listed configurations available for utility rebate and compliance support.

Specifications

  • Nominal Length: 4'
  • Input Voltage: 120-277V
  • Color Temperature Options: 3500K | 5000K
  • Light Bar Quantity: 1
  • Driver Power Settings: 14W | 18W | 22W
  • Lumen Output (Bare Light Bar): 2200 | 2900 | 3520 (3500K) / 2300 | 2900 | 3600 (5000K)
  • Efficacy: up to 164 lm/W
  • Dimming: 0-10V, dims to 10%
  • Operating Ambient Temperature: -4�b0F to 122�b0F (-20�b0C to 50�b0C)
  • Rated Life (L70): up to 100,000 hours
  • Construction: Plastic housing with polycarbonate frosted lens

Common Uses

Ideal for retrofitting strip fixtures, wraparounds, and other linear luminaires in offices, schools, utility areas, storage rooms, and light industrial facilities where efficient, controllable illumination is needed.

RESOURCES AND DOWNLOADS

Universal Light Bar Kit Spec Sheet
